Thickener Drive Head Manufacturer
Mineral Tech Pro manufactures thickener drive heads and supplies replacement thickener drive heads for retrofit programmes. Specify a new hydraulic thickener drive or match an existing Series A–Eb unit — continuous ratings up to 7.5 million Nm, with thickener drive retrofit support from Bangalore.
Ø100m
Max thickener diameter
7.5M Nm
Drive head rating
12M Nm
Series D centre column
All sizes
Replacement drive heads
Selection for new builds and replacements
Lead with process and mechanical requirements — series names come after the duty is clear.
Step 1
Define duty
Tank diameter, slurry density, underflow solids target, continuous vs paste duty, and whether the unit is bridge- or centre-column mounted.
Step 2
Match torque class
Use continuous operating torque and peak cutoff to shortlist Series A–Eb. Paste thickeners typically need Ea (under 25m) or Eb (over 25m).
Step 3
Confirm retrofit fit
For replacements, share existing drive footprint, output shaft, pinion count, lift arrangement and control interfaces so MTP can check drop-in compatibility.
Step 4
Plan installation
Bridge or pier mounting, hydraulic vs mechanical lift, load-cell verification and commissioning support are agreed before fabrication release.
Replacement compatibility
MTP drive heads of all sizes are available as replacement units, built to the same standards as original equipment. They are suitable for retrofit and aftermarket programmes when footprint, torque class and lift architecture can be matched.
- Existing series / model and continuous torque rating
- Tank diameter and bridge vs centre-pier mount
- Output interface, pinion count and rake lift type
- Hydraulic power unit and control / overload scheme
- Site access, crane lift and downtime window
Installation requirements
Final selection is confirmed from process duty and site economics. Mechanical or hydraulic drives are available up to 20m diameter; hydraulic drives are used above 20m. Rake lifting is available on all thickener designs.
- Foundation / pier readiness and alignment tolerances
- Bridge structural checks for drive and lift loads
- Utility connections for hydraulics and instrumentation
- Factory load-cell verification before despatch
- On-site mechanical and process commissioning support
Series comparison
Series A–Eb comparison
Specs below match the MTP Company Profile 2026 thickener ranges. Use the table to compare continuous torque, tank diameter span, gearing and lift architecture.
| Series | Continuous | Peak Cutoff | Tank Ø Span | Drive Gearing | Lift Architecture | |
|---|---|---|---|---|---|---|
Series A MTP Series A Direct drive with rake lifting | — | — | Application sized | Direct drive | Rake lifting | Enquire |
Series B MTP Series B Direct drive with rake lifting and slewing ring | — | — | Application sized | Direct drive + slewing ring | Rake lifting | Enquire |
Series C MTP Series C Centre column design | Up to 6M Nm | Up to 6M Nm | Larger tanks / column mount | Centre column | Rake lifting | Enquire |
Series D MTP Series D Centre column high-capacity design | Up to 12M Nm | Up to 12M Nm | Large-diameter thickeners | Centre column | Rake lifting | Enquire |
Series Ea MTP Series Ea Hi-torque for paste thickeners under 25m | Hi-torque paste duty | Hi-torque paste duty | Under 25 m | Paste thickener duty | Rake lifting | Enquire |
Series Eb MTP Series Eb Hi-torque for paste thickeners over 25m | Hi-torque paste duty | Up to 7.5M Nm class | Over 25 m | Paste thickener duty | Rake lifting | Enquire |
Drive architecture
Mechanical features that protect uptime
Innovative feed dilution
MTP thickeners and clarifiers incorporate an innovative feed dilution system as part of up-to-date process and mechanical design thinking.
- Mineral-industry specific designs
- Heavy-duty drive units
- Client-tailored solutions
Bridge or centre-column mount
Up to 35m diameter: central bridge-mounted drive. For 35–40m, designs are available with either bridge or central column mounted drives — chosen by local site economics and client preference.
- Bridge mount ≤35m
- Bridge or column 35–40m
- Hydraulic drives above 20m
Rake lifting on all designs
Rake lifting is available on all thickener designs. Mechanical or hydraulic drives up to 20m diameter; hydraulic drives above 20m.
- All series support rake lift
- Mechanical or hydraulic ≤20m
- Hydraulic >20m
Replacement drive heads
MTP drive heads of all sizes are available as replacement drive heads, built to the same high standards as original equipment.
- Drop-in replacement program
- OEM quality standards
- Aftermarket documentation
Indicative sizing
Thickener drive sizing calculator
Estimate continuous operating torque and a recommended series. Results are indicative only — final selection is confirmed by engineering review against your duty data.
Estimated Load Parameters • Compliant
Continuous Operating Torque
191 kNm
Design peak torque threshold: 382 kNm
Recommended OEM Model
Series A / B (MTP Series A or B)
Direct drive with rake lifting (B includes slewing ring)
Factory verification & load-cell testing
- Capital equipment supply with aftermarket documentation
- Installation, assembly & mechanical commissioning
- Process commissioning and fine-tuning
- On-site inspections and operator training
- Equipment rebuild and refurbishment
- Spare and wear parts management
